Sierra Patio Cover Awning

The Sierra Palram Polycarbonate Patio Cover (7.4 ft deep x 7.4 ft width extensions) offers strong protection from the elements. It comes with a 7 year warranty and is ideal for Canadian winter. This robust shelter sheds snow/hail and ice with a 24 lbs/square foot snow load and wind rating up to 56 mph. It comes with 6 mm thick twin wall unbreakable polycarbonate panels, rain gutters and leg anchors.

Contact us for quotes to go wider than 14.8 feet (must be 7.4 foot increments).

• Safe ultra-durable, polycarbonate patio cover, and multi-functional outdoor structure, designed for superior protection all year-round
• Provides up to 100% protection from harmful UV sunrays, while transmitting natural sun light
• White and grey frame with clear panels blocks 20% of light transmission

• Life-time resilient polycarbonate glazing; does not fracture, become brittle or turn yellow over time
• Proprietary screw-free roofing assembly system, specially developed to prevent rain/dew leaks
• Firm, anti-rust aluminum structure, specially engineered to withstand harsh weather conditions
• Allows an extended use of your backyard throughout the year
• Clean-lined, modern design
• Friendly and safe DIY assembly structure

NOTE: To connect 2 or more of these awnings together side-by-side you will need the EZ Connector Accessory Kit.

Ships From Mississauga, Ontario

Polycarbonate Panels
Virtually unbreakable 6 mm twin-wall polycarbonate roof panels offer high impact, shatter resistance and protection from inclement weather. They maintain their integrity, provide complete UV blockage, and are 100% UV protected. They also do not discolor, fracture or become brittle over time and come ready to assemble pre-cut panels. Safe, quick and easy DIY assembly with sliding roof panels installation.

Aluminum Structure
Rust-resistant powder-coated frame made of heavy duty aluminum and laser cut galvanized steel connectors. Ready to assemble pre-drilled profiles.

Adjustable Installation
Wall mounting plate is adjustable to meet your desired height between 260-305 cm (101.2 in. - 120 in.); allowing a flexible positioning of the roof slope enabling snow and rain to slide off. Adjustable oval poles allow for ideal positioning: left to right 0-54 cm (0 in. - 21.2 in.) and front to back 226-286 cm (89 in. - 112.6)

Gutter & Gutter Heads
Integrated gutter and adjustable gutter heads allow you to easily channel and collect rainwater for a sustainable irrigation system

Anchoring
Requires a solid level surface and solid wall support, Anchoring included Secure the patio cover to the surface of your choosing to make the most of your sturdy structure, increase its stability and improve its weather resistance
Sturdy, oval aluminum poles

Technical Specifications

WHITE FRAME / CLEAR GLAZING
WIND RESISTANCE – 90km/hr | 56ml/hr
SNOW LOAD – 120kg/m | 24.6lbs/ft
LIGHT TRANSMISSION – 80%
POLYCARBONATE PANEL – 6mm

GREY FRAME / CLEAR GLAZING
WIND RESISTANCE – 90km/hr | 56ml/hr
SNOW LOAD – 120kg/m | 24.6lbs/ft
LIGHT TRANSMISSION – 80%
POLYCARBONATE PANEL – 6mm

Download Assembly Manual Here

Customer's Sierra Awning Installed by SumToolBox in Toronto Area.
Click here for installers you may wish to contact directly.
